Transmission-Clutch - Zodiac International

710753 - GZP The Cure BT82-86 2-pc sprocket spacer w/

NOTE: The images shown are for reference only, the actual product may differ.
Therefore please always read the description or read on the corresponding catalog page.

Enlarge article image

GZP The Cure BT82-86 2-pc sprocket spacer w/

Article-No.: 710753
60,65 €

Part Description

"The Cure" main drive gear seal kits, Fits 1982-1986 4-speed Big Twin

Text excerpt from the catalog:

Every 4-speed Big Twin rider knows "The Leak": the ever-present oil leak from the main drive gear. Now Zodiac has "The Cure", a seal kit that will stop this oil leak! The stable and reliable Harley-Davidson 4-speed transmission has been built for half a century, but the oil leak has always been present. The reason is that Harley-Davidson designed the main drive gear spacer without a seal. This state of the art hardened two piece stainless steel spacer features an additional Viton O-ring that permanently prevents oil coming out between the spacer and the main drive gear. It can be installed easily without disassembly of the transmission as it is located just behind the main shaft oil seal. Kits replace the OEM 35171-37 spacers 1937-early 1977, OEM 35070-77 late 1977-1979, OEM 35070-80 1980-1981 and 35079-82A 1982-1985. They include the spacer washer, spacer sleeve, Viton O-ring and detailed installation instructions. Order the Total Cure kit when you do not have the main drive seal.

Spezification

Article-No.:
710753
Manufacturer/Distribution:
Zodiac Genuine / Zodiac International
Packaging Unit:
1
OEM Referenz:
35079-82A
Catalog page:
640
